端面彈簧釜用機械密封件的標準型號規格表
來源：廣東東晟密封科技有限公司 - m.chbabys.com更新時間：2016-11-19
東晟機械密封件告訴您雙端面小彈簧釜用機械密封件的型號規格都有什么？
|
攪拌軸軸徑 |
d(h9) |
D |
D1 |
D2 |
Hmax |
n-ф |
h |
|
|
30mm |
30mm |
235mm |
190mm |
156mm |
360mm |
8-22mm |
24mm |
|
|
40mm |
40mm |
235mm |
190mm |
156mm |
360mm |
8-22mm |
24mm |
|
|
50mm |
50mm |
270mm |
220mm |
184mm |
380mm |
8-26mm |
26mm |
|
|
60mm |
60mm |
270mm |
220mm |
184mm |
380mm |
8-26mm |
26mm |
|
|
80mm |
80mm |
300mm |
250mm |
211mm |
405mm |
8-26mm |
28mm |
|
|
90mm |
90mm |
360mm |
310mm |
274mm |
420mm |
12-26mm |
30mm |
|
|
100mm |
100mm |
360mm |
310mm |
274mm |
430mm |
12-26mm |
30mm |
|
|
110mm |
110mm |
360mm |
310mm |
274mm |
435mm |
12-26mm |
30mm |
|
|
120mm |
120mm |
360mm |
310mm |
274mm |
445mm |
12-26mm |
30mm |
|
|
130mm |
130mm |
360mm |
310mm |
274mm |
460mm |
12-26mm |
30mm |
|
|
140mm |
140mm |
425mm |
370mm |
330mm |
475mm |
12-30mm |
32mm |
|
|
160mm |
160mm |
425mm |
370mm |
330mm |
495mm |
12-30mm |
32mm |
|
|
180mm |
180mm |
485mm |
430mm |
389mm |
515mm |
16-30mm |
34mm |
|
|
200mm |
200mm |
555mm |
490mm |
448mm |
535mm |
16-33mm |
38mm |
|
|
220mm |
220mm |
620mm |
550mm |
503mm |
365mm |
16-36mm |
40mm |
|
|
密封件的參數單位代號都代表什么？ |
D1-機械密封圈的公稱外徑； d1-機械密封圈的公稱內徑； D-釜用機械密封圈內徑； d-釜用機械密封圈直徑； d2-釜用機械密封圈的寬度； |
|||||||
